Automatic Can Filling Machine-non-carbonated Drinks
This machine is suitbale for plastic and aluminum cans, non-carbonated drinks, function for filling and cap sealing.
Quantity:
- Model: XGF-C
- Brand: LINKS MACHINERY
- Code: 8422301090
Product Description
Automatic Can Filling Machine (juice, water, non-carbonated...ect)
①. More reasonable and beautiful overall structure
②. Obvious bigger seaming head, adopt heavy bearing which prolong the seaming cam service, the normal service time could prolong 5 times and more.
③. Twin shafts structure: The first seaming roll and the second seaming roll are separated. User could adjust and control the seaming rolls separately.
④. The rotation direction is anticlockwise direction in seaming process; the seamed cans leave the seamer automatically as its direction to avoid jam and scratch
⑤. Filling cylinder is arc structure, no dead angle to avoid liquid left. It adopts CIP automatic clean design to clean.
①. More reasonable and beautiful overall structure
②. Obvious bigger seaming head, adopt heavy bearing which prolong the seaming cam service, the normal service time could prolong 5 times and more.
③. Twin shafts structure: The first seaming roll and the second seaming roll are separated. User could adjust and control the seaming rolls separately.
④. The rotation direction is anticlockwise direction in seaming process; the seamed cans leave the seamer automatically as its direction to avoid jam and scratch
⑤. Filling cylinder is arc structure, no dead angle to avoid liquid left. It adopts CIP automatic clean design to clean.
| Model | Filling heads | Capping heads | Capacity cans/min | Power | Weight (kgs) | Size (mm) |
| YLG12-4 | 12 | 4 | 30-170 | 5.5kw | 3100 | 2850*1500*1900 |
| YLG18-4 | 18 | 4 | 30-250 | 5.5kw | 3800 | 3050*1750*1900 |
| YLG36-6 | 36 | 6 | 80-400 | 7.5kw | 5000 | 3660*2530*1900 |
| YLG48-8 | 48 | 8 | 80-600 | 11kw | 7750 | 3960*2830*1900 |
| YLG12-1 | 12 | 1 | 30 | 2.5kw | 2100 | 2500*1500*1800 |
| | | | | | | |
| No. | Name of parts | Producing area |
| 1 | Programmed controller | MitsubishiJapan |
| 2 | Low-pressure breaker | Siemens Germany |
| 3 | AC electromagnetic contractor | Siemens Germany |
| 4 | AC electromagnetic contractor | Siemens Germany |
| 5 | Heat-break device | Siemens Germany |
| 6 | Multi-continuous electrical device | Siemens Germany |
| 7 | Middle-continuous electrical device | Omron Japan |
| 8 | Inducing on-off | AUTONICS USA |
1) Can your factory provide the whole plant from A to Z?
A: Yes, we can provide the complete plant, from bottling making plant, water purification plant, to filling packing plant.
2) How can I know the machinery quality before I order?
A: Frist, we will invite you visiting our factory to check the machines quality, and show the machines running for you in our factory.
3)What certificates you can provide?
A: Our factory provide the CE, SGS, ISO, and accroding to some countries, we also can provide the Pvoc, Coc, Soncap...ect
4)Can your factory make the bottle drawing, workshop layout, and labels for us?
A: We can help customers design their own bottle shape, workshop layout and label drawings, these jobs are free charge.
(Workshop need customer to provide the size of factory)
5)Installation and Training Time
A: We have professional engineer for oversea installaion and training, they can speak English, and have much experience oversea work.
Customer needs to provide the engineer visa, air tickets, sleep room and meals. Each day salary is 80usd, around 20-40days.
6) Warranty time:
We provide the 18 months as our machinery parts warranty time, and electric parts warranty time is 12 month.
